BENINCA - IRREVERSIBLE 24 VDC ELECTROMECHANICAL GEARED MOTOR, LINEAR WORM SCREWS, FOR SWING GATES UP TO 5 MT PER LEAF
- GEARED MOTOR FOR INTENSIVE USE, EQUIPPED WITH ENCODER
- THE ENCODER DEVICE ENSURES MAXIMUM SAFETY AND PRECISION IN THE GATE MOVING PHASES
- AMPEROMETRIC SENSOR OBSTACLE DETECTION SYSTEM TO PREVENT CRUSHING
- OPTIONAL BATTERY POWERED OPERATION
IRREVERSIBLE ELECTROMECHANICAL GEARED MOTOR
BOB5024E 9591328
TECHNICAL DETAILS:
MAINS SUPPLY: 230 Vac (50-60HZ)
MOTOR POWER SUPPLY: 24Vdc
MAX CURRENT: 6,7 A
MAXIMUM THRUST: 2200N
OPENING TIME: 21''
WORKING CYCLE: intensive use
STANDARD STROKE: 455 mm
MAXIMUM STROKE: 520 mm
INDEX OF PROTECTION: IP44
OPERATING TEMPERATURE: -20°C / +50°C
LEAF MAX DIMENSION: 5 m
