VORTICE - MANUAL HAND-DRYER
• FRONT COVER MADE OF UV-RESISTANT PLASTIC RATED V0, COLOUR WHITE.
• WALL-MOUNTING FLANGE INCORPORATING WARM AIR OUTLET GRILLE OF MOULDED PLASTIC (PP).
• EC MOTOR WITH THERMAL OVERLOAD CUTOUT AND SHAFT TURNING IN BALL BEARINGS, COUPLED TO FORWARD-BLADED CENTRIFUGAL IMPELLER.
• HEATING ELEMENT PROTECTED BY 2 DEVICES: THERMAL FUSE AND RESETTABLE THERMAL OVERLOAD LIMITER.
• AIR FLOW 170 M3/H.
• DRYER OPERATED MANUALLY BY PUSH BUTTON. EQUIPPED WITH ELECTRONIC TIMER DESIGNED TO SHUT OFF THE FAN MOTOR AUTOMATICALLY AFTER A SET INTERVAL, SELECTABLE DURING INSTALLATION IN THE RANGE 20"-60". APPLIANCE SHUTS DOWN AUTOMATICALLY IN THE EVENT OF THE AIR INLET GRILLE OR THE WARM AIR OUTLET NOZZLE BEING OBSTRUCTED INTENTIONALLY OR ACCIDENTALLY.
• DUST FILTER.
• IMQ SAFETY CERTIFICATION.
OPTIMAL DRY Serie 19226
ABSORBED CURRENT MAX (A): 9
ABSORBED POWER MAX (W): 2000
FREQUENCY (HZ): 50-60
INSULATION CLASS: II°
IP: X4
MOTOR POWER (W): 65
SHOCK RESISTANCE RATING (IK): 09
VOLTAGE (V): 220-240
WEIGHT (KG): 2,6
AIRFLOW SPEED AT MAX SPEED (M/S): 14
DELIVERY MAX (L/S): 47
DELIVERY MAX (M³/H): 220
POWER IN STAND-BY MODE (W): 0,4060
SOUND PRESSURE LEVEL LP [DB (A)] 1M: 61,4
TEMPO ASCIUGATURA (S): 25
VELOCITÀ ARIA (KM/H): 50
SIZE A (MM): 253
SIZE B (MM): 319
SIZE C (MM): 137
SIZE D (MM): 220
