VDS - 230V REVERSIBLE LINEAR ELECTROMECHANICAL ACTUATOR FOR DOORS UP TO 5 METRES AND 600KG
- EQUIPPED WITH ELECTROMECHANICAL OPENING/CLOSING LIMIT SWITCH
- FOR SEMI-INTENSIVE USE, FREQUENCY OF USE 60%
- OPENING SPEED 16.2 METRES PER MINUTE
- USEFUL STROKE 415MM
- HIGH PERFORMANCE ELECTRIC MOTOR
- MAXIMUM SILENT OPERATION
- MANUAL RELEASE WITH KEY
- EQUIPPED WITH ANTI-CRUSHING DEVICE, SPEED REDUCTION
MORAN25-R REQUIRES AN ELECTRIC LOCK AND FOR DOORS OVER 3 METRES IN HEIGHT, AN ELECTRONIC CONTROL UNIT WITH FINAL SLOWDOWN MUST BE USED.
VDS - MORAN25-R
300085R
TECHNICAL FEATURES :
MOTOR POWER SUPPLY: 230V
MAX LEAF WEIGHT: 600KG
MAX LEAF SIZE: 5MT
AVERAGE POWER CONSUMPTION: 1 A
MOTOR POWER: 200W
CAPACITOR: 6.3 MF
OPERATING TEMPERATURE: -20 / 70°C
PROTECTION RATING: IP55
