NICE - WI-FI-RADIO GATEWAY MODULE ALLOWING MANAGEMENT OF NICE AUTOMATIONS VIA MyNice App.
- VIA WI-FI COMMUNICATION ALLOWS NICE AUTOMATIONS WITH INTEGRATED OR OPTIONAL RADIO RECEIVER TO BE CONNECTED AND INTERACT, EVEN REMOTELY
- EASY CONFIGURATION OF INTERACTIONS BETWEEN AUTOMATIONS AND SCENARIO PROGRAMMING
- THE TWO-WAY RADIO PROTOCOL USES GFSK MODULATION, WHICH PROVIDES GREATER IMMUNITY TO INTERFERENCE
- COMPATIBLE WITH PREVIOUS VERSIONS OF PLUG-IN AND EXTERNAL NICE RECEIVERS IN ONE-WAY ROLLING CODE MODE.
WI-FI RADIO GATEWAY MODULE
CORE
TECHNICAL CHARACTERISTICS:
- INPUT: 5V
- OPTIONAL BATTERY POWER SUPPLY: 2X AA RECHARGEABLE NIMH
- MAXIMUM POWER ABSORPTION (W): 1,5
- WIFI INTERFACE TYPE WITH INTERNAL ANTENNA: 802.11B/G/N – 2,4 GHZ (P<10MW)
- SECURITY: OPEN/WEP/WPA-PSK/WPA2-PS
- SUPPORT: WPS
- DUAL FREQUENCY RADIO TRANSMISSION: DUAL BAND BIDIRECTIONAL 433.54 - 433.92 MHZ/868.3 - 868.94 MHZ (P<10MW)
- RADIO RANGE IN FREE SPACE, IN THE ABSENCE OF INTERFERENCE: 500M (MAX. MESH NETWORK); 150M (IF INSIDE BUILDINGS)
- DEGREE OF PROTECTION (IP): 30
- OPERATING TEMPERATURE (°C MIN/MAX) -20 ÷ +50
- DIMENSIONS (MM): 113X64X33.
