GENIUS - FIRMWARE UPGRADE INTERFACE
- IT ALLOWS FIRMWARE UPDATE VIA USB STICK
- XUSB CONNECTS DIRECTLY TO THE DEDICATED CONNECTORS, PROVIDING A USEFUL UPGRADE TOOL IN CASE THERE IS NO USB PORT ON THE CIRCUIT BOARD
- ONCE THE UPGRADE IS DONE, SIMPLY REMOVE XUSB TO EMPLOY IT ON OTHER COMPATIBLE SYSTEMS, PROVIDING MAXIMUM VERSATILITY.
GENIUS - XUSB
202274
TECHNICAL FEATURES:
POWER SUPPLY VOLTAGE: 24V from control board
ABSORPTION WITHOUT USB STICK: 30 mA @ 5V (7mA @ 24V for accessory absorption calculation)
OPERATING TEMPERATURE (°C): -20 +55
USB TYPE: USB 2.0 FAT or FAT 32
