FADINI - ELECTRONIC CARD FOR ELPRO 43 SWING GATES
ELECTRONIC BOARD FOR DARDO 430, COMPLETE WITH OUTDOOR CONTAINER
MAIN FUNCTIONS: DSA PHOTOCELL CONTROL, DEDICATED OUTPUT FOR ELECTRIC LOCK, DEDICATED INPUTS FOR SAFETY SENSITIVE EDGES, SPEED, FORCE AND PAUSE ADJUSTMENT WITH TRIMMER. DEDICATED OUTPUTS FOR 2 MOTORS.
AUTOMATIC PROGRAMMING OF THE WORKING TIME, WITH OR WITHOUT LEAF DELAY, WITH FIXED SLOWDOWN
DURING OPENING AND CLOSING. AMPEROMETRIC FUNCTION AND ENCODER FOR REVERSAL ON IMPACT
(THE PICTURE IS INDICATIVE AND COULD BE DIFFERENT FROM THE REAL PRODUCT)
ELPRO 43 4300L
230 V AC
TECHNICAL DETAILS
Single-phase board power supply: 230 V ±10% 50 Hz
Max motor power: 500 W
Courtesy light output: 24 V - 50 mA max.
Photocells/selector/receiver radio output: 24 Vdc - 500 mA max
Signal light output: 24 V - 1 W
DSA control output: 24 V dc
Flashing output: 230 V - 25 W
Pause time: 1 - 120 s
Box dimensions: 210 x 295 x 110 mm
Degree of protection: IP 64
Operating temperature: -20 °C +55 °C
