FAAC - ELECTROMECHANICAL GEARMOTOR, FOR SLIDING GATES WEIGHING UP TO 900 KG PER LEAF
- E781 ELECTRONIC EQUIPMENT INTEGRATED IN AUTOMATION
- ADVANCED GEARMOTOR: INTEGRATED CONTROL UNIT WITH ADJUSTABLE SPEED
- HIGH PERFORMANCE MOTOR CONTROL
- EQUIPPED WITH HIGH-RESOLUTION MAGNETIC ENCODER FOR SMOOTH OPERATION
GEARMOTOR 741 C
109602
230Vac
TECHNICAL FEATURES:
Mains supply voltage: 220-240V~ 50/60 Hz
Electric motor: Single-phase asynchronous
Power: Max. 530 W
Max. torque: 20 Nm (*)
Max. thrust: 630 N (*)
Reduction ratio 1:25
Max. leaf width 15 m
Leaf speed 12 m/min
Speed regulation and motor control: Yes
Magnetic limit switch
Pinion Z16 module 4
Encoder: Magnetic encoder
Force regulation: Via electronic card
Ambient operating temperature -20°C to +55°C (**)
Self-resetting 140°C thermal protection
Degree of protection IP44
Weight 13.1 kg
Dimensions (WxDxH) 295 x 180 x 320 mm
Max. door weight 900 kg
Frequency of use 56 cycles/h
Built-in electronic equipment
Release device Rotary release knob - coded key
Starting capacitor 12.5 μF
