faac gearmotor 746 c z16 109745

SKU: 109745

€1,150.00  €690.00VAT INCLUDED

FAAC - 230V GEARMOTOR FOR SLIDING GATES WITH LEAF WEIGHT MAX. 600KG.

- RENEWED GEARMOTOR WITH INTEGRATED E781 ELECTRONIC CONTROL BOARD FEATURING ADJUSTABLE SPEED CONTROL LEVELS
- IT INCLUDES TWO DEDICATED INPUTS FOR SAFETY EDGES (NC OR 8.2 KOHM)
- NEW RETROACTIVE MOTOR CONTROL WITH HIGH-RESOLUTION ENCODER
- COMPATIBLE WITH SIMPLY CONNECT AND THE NEW FDS RADIO TECHNOLOGY
- PINION Z16 MODULE 4.


FAAC - 746 C Z16
109745


TECHNICAL CHARACTERISTICS:
MAINS SUPPLY VOLTAGE: 220-240V - 50/60 HZ
MAX POWER: 150W
PINION: Z16 MODULE 4
MAX. FORCE OF PUSH: 830N
MAX. WEIGHT LEAF: 600KG
MAX. LEAF SPEED: 9.6M/MIN
MAX. LEAF LENGTH: 40M
STOPPING SPACE: 30MM
DEGREE OF PROTECTION: IP44
INRUSH CAPACITOR: 12,5 µF
AMBIENT OPERATING TEMPERATURE: -20° ÷ +55°
THERMAL INSULATION:120° SELF-RESTORING
ELECTRONIC EQUIPMENT: E781 BUILT-IN.

  • Brand: FAAC
