CAME - MONDRIAN 4 GEARMOTOR - Ø 35 230 V AC- 50 HZ FAST WITH MECHANICAL LIMIT SWITCH
- OPTIONAL EXTERNAL RECEIVER
- CAN BE USED ON Ø 40 MM ROUND OR OCTAGONAL TUBES
- MANUAL MECHANICAL LIMIT SWITCH WITH PROGRESSIVE SCREW ADJUSTMENT
- IDEAL FOR SMALL BOXES.
- UNIVERSAL HEAD FOR APPLICATION OF ANY FASTENING PLATE
Technical Features:
-Torque (Nm) 6
-Speed RPM (Revolutions per minute) 28
-Lifted weight (kg)* 17
-Tours of Limit switches (Tours) 39
-Operating time (Min) 4
-Degree of protection (IP) 44
-Absorption (A) 0.53
-Power (W) 121
-Length (mm) = L1 432
-Weight (kg) 1.46
MONDRIAN 4 - Ø 35 001Y4006A283MO
230 V AC- 50 Hz
