BENINCA - IRREVERSIBLE ELECTROMECHANICAL GEARMOTOR, LINEAR WORM GEAR MOVEMENT, FOR SWING GATES WITH LEAVES UP TO 5 MT
- GEARMOTOR RELIABLE AND QUICK TO INSTALL, THANKS TO 2 MECHANICAL STOPS ADJUSTABLE ON OPENING AND CLOSING.
- BRONZE REDUCTION GEAR AND NUT
- CUSTOMISED RELEASE KEY
- Ø 20 MM ROLLED SPHERICAL SECTION SCREW
- EASY-ACCESS TOP RELEASE
- EQUIPPED WITH EASILY ADJUSTABLE LIMIT SWITCHES
IRREVERSIBLE ELECTROMECHANICAL GEARMOTOR
BOB50M 9591022
TECHNICAL DETAILS:
MAINS SUPPLY: 230 Vac (50-60 Hz)
MOTOR POWER SUPPLY: 230 Vac
MAX CURRENT: 1,4 A
MAXIMUM THRUST: 3500N
OPENING TIME: 26''
WORKING CYCLE: 30%
STANDARD STROKE: 455 mm
MAXIMUM STROKE: 520 mm
INDEX OF PROTECTION: IP44
OPERATING TEMPERATURE: -20°C / +50°C
MAX LEAF LENGHT: 5 m
