BENINCA - IRREVERSIBLE ELECTROMECHANICAL GEARMOTOR, FOR COUNTERWEIGHTED OVERHED DOORS, WITH LEAVES UP TO 11 M2
- SUITABLE FOR RESIDENTIAL/CONDOMINIUM USE
- INTEGRATED COURTESY LIGHT, LIMIT SWITCHES AND CONTROL BUTTONS
IN THIS VERSION THE CONTROL UNIT, RECEIVER AND ENCODER ARE NOT INTEGRATED
GEARMOTOR FOR OVERHEAD DOORS
ZED.SC 9592635
TECHNICAL DETAILS:
MAINS SUPPLY: 230 Vac (50-60Hz)
MOTOR POWER SUPPLY: 230 Vac
MAXIMUM ABSORBED CURRENT: 1,5 A
DRIVE TORQUE: 350 Nm
OPENING TIME: 14”
WORKING CYCLE: 30%
INDEX OF PROTECTION: IP40
OPERATING TEMPERATURE: -20°C /+50°C
DOOR SURFACE: 11 m2/max
