BENINCA - FAST 24VDC GEARED MOTOR FOR INTENSIVE USE FOR SLIDING GATES UP TO 1200 KG OF WEIGHT.
- FAST 24 VDC GEARED MOTOR FOR INTENSIVE USE WITH OIL LUBRICATED REDUCTIONS
- CONTROL UNIT EQUIPPED WITH SWITCHING POWER SUPPLY (115/230 VAC) THAT ALLOWS REDUCED POWER USE AND LONG LIFESPAN OF THE ACTUATOR
- THE MAIN CONTROL UNIT, ON THE TOP PART OF THE MOTOR, MAKES IT
POSSIBLE TO FACILITATE THE WIRING PROCEDURE AND ALSO TO CALCULATE THE POSITION OF THE MOTOR STARTING FROM THE MEASUREMENT OF INSTANTANEOUS SPEED (VIRTUAL ENCODER)
- THE VIRTUAL ENCODER ALLOWS PROPER MANAGEMENT
OF THE SLOWING-DOWN PHASES, MOVEMENT TRACKING (STC SYSTEM),
AND TORQUE MANAGEMENT IN RELATION TO THE POSITION OF THE GATE, WHICH GUARANTEES MAXIMUM SAFETY
- SELF-PROGRAMMING WITH TRANSMITTER CAN BE ACTIVATED
AT THE FIRST INSTALLATION. PRACTICAL CABLEGUIDES
- MAXIMUM PERFORMANCE AND SPEED (24 M/MIN WITH 1200 KG)
- ANTI-CRUSHING SYSTEM WITH AMPEROMETRIC OBSTACLE DETECTION
- SAFETY SENSOR THAT STOPS THE MOTOR POWER SUPPLY DURING RELEASE OPERATIONS
- DESIGNED FOR CONNECTION TO THE X.BE MODULE TO INTEGRATE
THE DEVICE INTO KNX HOME AUTOMATION SYSTEMS
- CONVENIENT COMPARTMENT FOR 2 MOD. DA.BT6 7 AH BATTERIES
- METAL RELEASE LEVER
- OPTION TO OPERATE OPPOSED SLIDING GATES USING THE SIS ACCESSORY
- VERSION WITH MAGNETIC LIMIT SWITCHES
GEARED MOTOR FOR SLIDING GATES
BULL1224TURBO.S 959000976
TECHNICAL DETAILS:
Power supply: 115 Vac / 230 Vac (50-60Hz)
Motor supply: 24 Vdc
Max absorbed current: 3 A
Power consumption in stand-by: 8 mA
Max Thrust: 390 N
Opening speed: 12,5÷24 m/min
Duty cycle: 80% (the cycle falls to 40% in extreme operating conditions)
Protection level: IP44
Magnetic limit switches: YES
Operating temperature: -20°C /+50°C
