BENINCA - CONTROL UNIT FOR 1 OR 2 ACTUATORS FOR SWING GATES, OPPOSING SLIDING GATES AND FOLDING INDUSTRIAL DOORS WITH UP TO 2 LEAVES.
- INTEGRATED LCD DISPLAY
- INTEGRATED RADIO RECEIVER 433.92 MHZ 64 CODES AND 3 RADIO ENCODINGS (ADVANCED ROLLING CODE, ROLLING CODE, FIXED CODE)
- REMOVABLE TERMINAL BLOCKS
- SEPARATE LIMIT SWITCH INPUTS FOR EACH MOTOR
- OPEN, CLOSE, STEP-BY-STEP, PEDESTRIAN AND STOP INPUTS
- SEPARATE INPUTS FOR ACTIVE PHOTOCELL IN OPEN-CLOSE MODE
- INPUT FOR SENSITIVE EDGE N.C. OR 8K2
- INPUT FOR HYDRAULIC MOTOR ENCODER 24Vdc
- OUTPUT FOR ELECTRONIC LOCK 12 VDC
- 2 OUTPUTS CONFIGURABLE AS WARNING LIGHTS OR OPEN GATE ALARM, SECOND RADIO CHANNEL, COURTESY LIGHT, ZONE LIGHT, PHOTOCELL TEST OR NC INPUT ALARM
- OUTPUT FOR FLASHING LIGHT CONNECTION
- AUTOSET OF OPERATING PARAMETERS TO SIMPLIFY INSTALLATION AND TESTING OF THE SYSTEM
- SEPARATE ELECTRONIC TORQUE AND SPEED CONTROL FOR EACH MOTOR
- ANTI-CRUSHING SAFETY WITH AMPEROMETRIC DETECTION AND ENCODER MANAGEMENT
- SEPARATELY ADJUSTABLE SLOWDOWNS FOR EACH MOTOR
- READY FOR MANAGEMENT, CONFIGURATION, DIAGNOSTICS AND FIRMWARE UPDATING THROUGH BeUP APP, THROUGH PRO.UP ACCESSORY
- POSSIBILITY OF PARAMETER CONFIGURATION AND RADIO CONTROL MANAGEMENT WITH ADVANTOUCH SYSTEM
- NUMBER OF MANOEUVRES
- PROGRAMMING ACCESS PASSWORD
- PROGRAMMABLE MAINTENANCE ALERT
- PREARRANGED FOR KNX CONNECTION VIA X.BE BOARD
INTEGRATED BATTERY CHARGER, COMPATIBLE WITH BATTERY MOD. DA.BT2/DA.BT6
CONTROL UNIT POWER SUPPLY: 115 o 230 Vac – 50/60 Hz
MOTOR POWER SUPPLY: 24 Vdc 240W + 240W
CONTROL UNIT
BRAINY24 PLUS 917603712
