BENINCA - CONTROL UNIT FOR 1 SLIDING GATE ACTUATOR BULL424ESA AND BULL624ESA SERIES.
CONTROL UNIT POWER SUPPLY 230Vac
MOTOR POWER SUPPLY: 24Vdc 80W
- INTEGRATED LCD DISPLAY
- INTEGRATED RADIO RECEIVER 433.92 MHZ 64 CODES AND ARC RADIO CODING
- INTEGRATED ESA SYSTEM ENERGY-SAVING DEVICE
- REMOVABLE TERMINAL BLOCKS
- AUTOMATIC, SEMI-AUTOMATIC AND DEAD MAN OPERATION LOGIC
- MOTOR LIMIT SWITCH INPUTS
- SEPARATE INPUTS FOR PHOTOCELL ACTIVE ON OPENING-CLOSING AND PHOTOCELL ACTIVE ONLY ON CLOSING
- PEDESTRIAN, STEP AND STOP INPUT
- INPUT FOR SENSITIVE EDGE N.C. OR 8K2
- TWO OUTPUTS CONFIGURABLE AS OPEN GATE WARNING LIGHT, SERVICE LIGHT, SECOND RADIO CHANNEL OR ZONE LIGHT
- PHOTOCELL TEST
- AUTOSET OPERATING PARAMETERS
- ELECTRONIC TORQUE CONTROL WITH AUTOMATIC CALCULATION FOR EACH POINT OF THE STROKE (STC SYSTEM)
- ANTI-CRUSHING SAFETY WITH AMPEROMETRIC DETECTION AND ENCODER MANAGEMENT
- ADJUSTABLE SLOWDOWNS
- POSSIBILITY OF PARAMETER CONFIGURATION AND RADIO CONTROL MANAGEMENT WITH ADVANTOUCH SYSTEM
- NUMBER OF MANOEUVRES
- PROGRAMMING ACCESS PASSWORD
- MAINTENANCE NOTICE.
CONTROL UNIT 24V
CP.B24ESA 9686693
